Gold Testing Equipment (Silicon Drift Detectors CGX-103)

About Gold Testing Equipment (Silicon Drift Detectors CGX-103)

Specifications :

• Detectable elements : Titanium to Uranium
• Measurement Results : Iron (Fe), Cobalt (Co), Nickel (Ni), Copper (Cu), Zinc (Zn), Ruthenium (Ru), Rhodium (Rh), Palladium (Pd), Silver (Ag), Cadmium (Cd), Indium (In), Tin (Sn), Osmium (Os), Iridium (Ir), Platinum (Pt), Gold(Au) - All metals separately.
• Accuracy of measurement : The accuracy of measurement is better than Silicon-Pin Detector
• Sensor : Silicon Drift Detector is used in place of Silicon-Pin Diode Detector for enhanced performance & spectral resolutions.
• Cooling for Detector : Thermoelectric
• Detecting Range : 0.1%-----99.99%
• Testing Time : 30-----200secs
• Test Spot Area : 0.5mm
• Power Supply : 90-240 V AC, 50/60Hz
• Power Rating : 30 Watt
• Working Temperature : 15-25^oC
• Relative humidity : <70%
• Operation atmosphere : Vibration free surface and air conditioned room
• Interface for Computer : Inbuilt (External Computer required)
• Software for Operation : Menu Driven User Friendly Operating System
• Dimensions of Instrument : Length : 335mm, Width : 225mm, Height : 210mm (with test compartment cover in closed position) & 330mm (in open position).
• Dimensions of Sample Chamber : Length : 235mm, Width : 195mm, Height : 80mm
• Net Weight : 12kg
