Gas Proportional XRF Detector

Detectable elements

Iron(Fe), Cobalt(Co), Nickel(Ni), Copper(Cu), Zinc(Zn), Ruthenium(Ru), Rhodium (Rh), Palladium (Pd), Silver (Ag),  Cadmium( Cd), Indium (In),Tin (Sn), Osmium (Os), Iredium (Ir), Platinum (Pt),Gold(Au)

Measurement Results

Cu (Combined with Fe, Co, Ni, Zn) Ag (Combined with Ru, Rh, Pd, Cd, In, Sn) Au (Combined with Os, Ir, Pt)

Accuracy of measurement

+/-0.3% (Molten Metal above 90% Au)

+/-0.5% (Molten Metal below 90% Au)

+/-1% (Molten Metal below 50% Au)

Sensor

Gas Proportional Counter Detector.

Cooling for Detector

Air

Detection Range

1%-99.99%

Testing Time

30-200 secs

Test Spot Area

0.3mm

High Voltage Source for X-Ray

<30µ

Power Supply

200-240V AC, 50-60Hz

Power Rating

130 Watt

Temperature Range

15-30^oC

Relative humidity

<70%

Operation atmosphere

Vibration free surface and air conditioned room.

Interface for Computer

Inbuilt (External Computer required).

Software for Operation

Menu Driven User Friendly Operating System.

Dimensions :

Length

440mm

Height

335mm (with test compartment cover in closed position) & 585mm (in open position).

Width

340mm (without connectors) and 370mm (with connectors)

Dimensions Length

255 mm

of Sample Chamber Height

55 mm

Width

255 mm

Net Weight

25 kg
