Auxiliary Display (Remote Wired)

Auxiliary Display (Remote Wired)
Auxiliary Display (Remote Wired)
Product Code : 39
Brand Name : Contech
Product Description

Auxiliary Display (Remote Wired)

Auxiliary Display is provided with Cable for viewing at a distance away from the scale which can be placed on the Tabletop or mounted on the Wall. Maximum cable length can be upto 25 mtrs.

Auxiliary Display is available in LED or VFD as per the provision in the scale

Salient Features :

  • Multiple Weighing Units:
    • Grams, Ounces, Troy Ounces, Carats, Mommes, Pennyweights, Grains, tola, Mesghal, Chinese taels.
  • Percentage Weighing :
    • Display of Reference weight, Sample weight, % of sample with respect to reference weight
  • Piece Counting:
    • Parts calibration using preset quantity of samples or programmable quantity.Automatic count correction for precise calibration.
  • Fill Mode :
    • 1 set point - Indication when sample weight exceeds the set limit.
    • 2 set points - Indication when the sample weight is between the lower & upper limits.
  • Accumulation:
    • Storage of maximum 200 samples.
  • Multiple Printing Mode:
    • 0,1,2,3 modes for various formats. Pause in case data storage capacity in a Printer is less.
  • Serial Interface:
    • RS 232 port with selectable baud rate 2400, 4800 Various interface formats adopting this Balance in a setup to replace any other leading international brand Balance.
  • External Calibration :
    • Using preset weights.
    • Known weights can be corrected to + 15 counts.
  • Response Time :
    • User selectable - Slow / Normal /Fast.
  • Stability Band Width :
    • Stability indicator "g" appears on display with counts variation + 1, + 2, +3, + 4.
  • Auto Zero Tracking:
    • User selectable 0,1,2,3
  • Return to Zero Tracking:
    • Variable : 0,2,3,4
  • Display Updation :
    • Speed setting : Fast / Normal.

Specification :

Taring Range

Up to full capacity

Response time

3 secs

Power Required

90-250V, 50/60Hz, 10 Watt

Operating Temperature

10 to 45 deg C
